PTW Machine systems are used to automatically weld the Flange plate to a web plate to form a Pre- fabricated Beam with twin wire feed system & flux automated feed as well as recovery system. In this H beam steel placed on work piece support frame & piece is moved outwards to the machine with the help of conveyer after submerged arc welding.

This machine is mainly used for submerged arc welding of assembled H Beam.

PTW machine capacity is 1000 tons per month.

H Beam Fabrication machine mainly consists of the host, input roller conveyor, output roller conveyor, hydraulic system, electrical control system, etc. It has the characteristics of precise positioning of workpieces, safety and stability, and improving production efficiency.

This machine is mainly used to fabricate H Beam in PEB with having capacity 1000 MT per month.

Radial drill machine is a type of drilling machine with a radial arm that allows the drill head to be positioned over a wide range of workpieces. This flexibility makes it suitable for drilling large or heavy parts, and parts with complex geometries. The machine typically has a heavy base, a vertical column, a radial arm that extends from the column, and a drill head mounted on the arm.

Radial drill machines are commonly used for drilling holes in Connection plates & base plates with mass drilling.

The machine can make maximum holes of 50mm dia. upto 45mm thick plate.

The operation in shearing machine is done by motor driven pump which forces the oil in cylinder against piston. The piston movement energizes the ram which is holding upper knife. Hydraulic shearing machine are able to take longer stokes as compare to other derived shearing machine.

Shearing machines are used to cut sheet metal, plates, and bars by applying shear stress, essentially slicing the material along a predetermined line.

Machine capacity is 1mm-12mm thickness with 2500mm width range.

Sand blasting machine assembly contains the air compressor, hopper, sand abrasive & hose pipe. For this sand blasting process, compressed air at tremendous velocity and pressure are presented on the blast wheel.

A sand blasting machine is principally used to eliminate rust, corrosion, and adulterant from the metal surface with the sustenance of abrasive media such as copper slag & sand.

Machine capacity is 1500MT in a month.

C & Z PURLIN MACHINE- C & Z forming machine have de coiler, flattening & guide system, forming system, hydraulic punching system & post cutter system guided by a control panel.

This machine is mainly used for to make C & Z section (Purlin & Girt).

Capacity of machine is 500MT in a month.

Deck sheet machine- Decking forming machine consists of de coiler and its base, coil sheet guiding equipment, roll forming system, post-cutting equipment, hydraulic station, PLC base controlling system, supporter table. The corrugated profile sheet produced by this machine has high strength with big rib, which adheres well to concrete.

Capacity of machine is 500MT in a month

Profile sheet roll forming machine consists of an automatic De coiler, feeding guide, roll forming unit, hydraulic cutter with PLC base control system. Highest output speeds up you 30-40 meters per minute results in at least 10-15 times higher production. Accuracy and consistency in shape & dimension can be achieved. Reduced delivery period to meet our production needs.

Roll forming machine is used to make roof sheet & wall cladding sheet.

Roll forming machine capacity 800MT per month. E

Rectangular duct machine of an automatic De coiler, feeding guide, roll forming unit, hydraulic cutter with PLC base control system. It is mainly controlled by cutting software.

Machine is mainly used for to make rectangular duct for HVAC system.

Machine capacity is 25000SQM per month.

Spiral duct machine consist of automatic de coiler, feeding guide, roll forming unit, hydraulic cutter with PLC base control system.

spiral duct machine is mainly used for to make spiral duct for HVAC system

Capacity is 80mm dia to 1600mm dia spiral pipe.

Oval duct machine consists of hydraulic press with manual control system.

This type of machine is used for to make oval duct for HVAC system.

Machine capacity range is 150mm- 450mm oval height.
